Garrett GT2876R (aka GT25-40R) Ball Bearing Turbo
Dual Ball Bearing GT25/40-R Turbo assembly with specified ar. T25 style inlet flange with 5 bolt style exit. Large 60- 1 style compressor housing with 4.00" inlet and 2.50" outlet. Very Good response turbo for 4 Cyl applications. This turbo has a flow capacity of about 450HP.
Turbine:
-Wheel: 53.9mm w/ 76 trim
-Housing: .64 ar, .86 ar
Compressor:
-Wheel: 76mm w/ 48 trim
-Housing: .70 ar
Applicable Garrett Part Numbers: 705330-5001S, 705330-5002S, 705330-0001, 705330-0002, 705330-1, 705330-2
Normally In Stock, Shipping Daily!
TurboKits.com only sells genuine Garrett turbochargers. Don’t fall victim to look alike or knockoff “Garrett” turbos from shady online retailers or auction sites. Rest assured that when you buy from TurboKits.com you are getting a quality, brand name turbocharger with the warranty and technical support to back it up.
| Turbine Housing Options | |||||
| Price | Inlet | Outlet | A/R | Type | |
| No Extra Cost | T25 | 5 Bolt | .64/.86 | Internal Wastegate |  |
| No Extra Cost | T3 | 4 Bolt | .63/.82 | External Wastegate |  |
| No Extra Cost | T3 | 5 Bolt | .63/.82 | External Wastegate |  |
| No Extra Cost | K24/K26 | 4 Bolt | .63/.82 | External Wastegate |  |
| $150.00 Extra | Tial Stainless Steel V-Band | V-Band | .52/.63/.82 | External Wastegate |  |
| No Extra Cost | T25 | T31 V-Band | .63/.82 | External Wastegate |  |
| No Extra Cost | T25 | 5 Bolt | .72 | External Wastegate |  |
| $389.29 Extra | Undivided V-Band | V-Band | .57/.72 | External Wastegate/Ni-Resist |  |
More Information
| Part Number | 836026-5005S, 705330-5002S, 705330-2 |
|---|---|
| Part Includes |
|
| Brand | Garrett |
| Type of Part | GT Ball Bearing |
| Horsepower Gains | 450 HP |
| Length | 14.0 |
| Width | 12.0 |
| Height | 10.0 |
| Weight | 35.000000 |
