Garrett GT2876R (aka GT25-40R) Ball Bearing Turbo

SKU
836026-5005S, 705330-5002S, 705330-2
Views: 2
Special Price $1,159.00 Regular Price $1,292.78



Garrett GT2876R (aka GT25-40R) Ball Bearing Turbo

Garrett Free Shipping

Dual Ball Bearing GT25/40-R Turbo assembly with specified ar. T25 style inlet flange with 5 bolt style exit. Large 60- 1 style compressor housing with 4.00" inlet and 2.50" outlet. Very Good response turbo for 4 Cyl applications. This turbo has a flow capacity of about 450HP.

Turbine:
-Wheel: 53.9mm w/ 76 trim
-Housing: .64 ar, .86 ar

Compressor:
-Wheel: 76mm w/ 48 trim
-Housing: .70 ar

Applicable Garrett Part Numbers: 705330-5001S, 705330-5002S, 705330-0001, 705330-0002, 705330-1, 705330-2

Normally In Stock, Shipping Daily!

TurboKits.com only sells genuine Garrett turbochargers. Don’t fall victim to look alike or knockoff “Garrett” turbos from shady online retailers or auction sites. Rest assured that when you buy from TurboKits.com you are getting a quality, brand name turbocharger with the warranty and technical support to back it up.

Turbine Housing Options
Price Inlet Outlet A/R Type
No Extra Cost T25 5 Bolt .64/.86 Internal Wastegate Garrett GT3582R T3 4 Bolt Turbine Housing
No Extra Cost T3 4 Bolt .63/.82 External Wastegate Garrett GT3582R T3 4 Bolt Turbine Housing
No Extra Cost T3 5 Bolt .63/.82 External Wastegate Garrett GT3582R T3 4 Bolt Turbine Housing
No Extra Cost K24/K26 4 Bolt .63/.82 External Wastegate Garrett GT3582R K24/K26 4 Bolt Turbine Housing
$150.00 Extra Tial Stainless Steel V-Band V-Band .52/.63/.82 External Wastegate Garrett GT3582R Tial Stainless Steel V-Band Turbine Housing
No Extra Cost T25 T31 V-Band .63/.82 External Wastegate Garrett GT3582R T25 V-Band Turbine Housing
No Extra Cost T25 5 Bolt .72 External Wastegate Garrett GT3582R T25 5 Bolt External Wastegate Turbine Housing
$389.29 Extra Undivided V-Band V-Band .57/.72 External Wastegate/Ni-Resist Garrett GT3582R T3 V-Band GT 3'' Outlet Turbine Housing
More Information
Part Number836026-5005S, 705330-5002S, 705330-2
Part Includes

  • Turbine
    • Wheel: 53mm w/ 62 trim
    • Housing: .64 ar, .86 ar
    • Ni-Resist Housing: .57ar, .72ar
  • Compressor
    • Wheel: 76mm w/ 48 trim
    • Housing: .70 ar

BrandGarrett
Type of PartGT Ball Bearing
Horsepower Gains450 HP
Length14.0
Width12.0
Height10.0
Weight35.000000
